Flo-Tite Inc. is a manufacturer of high quality ball valves and actuation equipment. Our products range from standard commercial type Ball Valves to high-pressure metal seated Control Valves. We maintain an inventory of standard valves in Carbon, Stainless Steel and Alloy 20.
All Valves are manufactured in strict adherence to internationally recognized standards and specifications, including ANSI/ASME/ISO/NACE and API. In addition to our standard products, we welcome the opportunity to design special Ball Valves and Castings for OEM requirements.
Threaded End – 1 & 2 Piece Body Design: General purpose ball valves commonly used in smaller sized pipelines under three inch in size. These valves tend to be used in more permanent applications where maintenance is seldom required.
Threaded End – 3 Piece Body Design: Three piece body valves area multi-purpose ball valves. They tend to be used in more demanding applications where maintenance will be required on a more frequent basis than 2 piece valves. The 3 piece body’s center section can be removed to allow the valve end caps to be welded without the possibility of damaging the valve seats. Any combination of end connections can be supplied to meet your custom requirements.\
Flanged End – 1 & 2 Piece Body Designs: A conventional design ball valve, made to be easily installed or removed from the pipeline. It is one of a few ball valves where its end-to-end or face-to-face dimensions is controlled by ANSI. Most all manufacturers conform to ANSI Guidelines.
Multi-Port Ball Valves: Multi-Port Ball Valves will lower overall cost by allowing the replacement of two or three conventional straight line valves, thus eliminating or reducing pipe fitting and expensive automation equipment.
| 1 & 2 PC Full Bore Fire Safe Valves
 1″ T23
 2″ S23
meets a wide range of applications.
|
FUSION SERIES
MODELS:
T23 – Full Port (2PC)
S23 – Seal Weld (1PC)
Features:
- Size Range: 1/4″ ~ 4″
- 1/4″ ~ 2″ – 2000 WOG
- 2 1/2″ ~ 4″ – 1500 WOG
- Steam T23 – 150 SWP S23 – 250 SWP
- Fire safe designed to API 607 4th edition
- Anti-Static Ground
- Locking handle and Oval handle
- Foundry heat numbers for all valves
- Metal nameplates identifies all soft parts
Download the Tech Bulletin Now!
|
| 1 PC Reduce Bore Threaded / Fire Safe
Economical 1-PC Design compact
uni-body delivers outstanding high pressure service in a cost effective package!
|
OMNI SERIES
MODEL:
T12
Maximum Pressures
2000 PSI CWP / 175 PSI SWP
Features:
- Stainless Steel 316 SS
- Carbon Steel WCB
- Adjustable stem packing
- Replaceable seats and seals
- Fire Safe Certified to API607 4thEdition
- Operating Range -20 ~ 450 F
- Sizes: 1/2″ through 2″
Download the Tech Bulletin Now!
|
| 2 PC Direct-Mount Automation Series
Eliminates Mounting Brackets and
all of their related problems.
designed for low profile, cost
effective industrial applications
|
DIRECT-MOUNT AUTOMATION SERIES
MODELS:
DM51 – BRASS PLATED BALL
DM52 – 316SS BALL/STEM
Features:
- Brass full port
- Low torque design
- 600 WOG – 150 WSP
- Temperature to 366 °F
MODEL:
DM80SS – STAINLESS STEEL
Features:
- Stainless Steel full port
- Low torque design
- 1000 WOG – 150 WSP
- Temperature to 370 °F
- High quality investment casting
Download the Tech Bulletin Now!
|
|
| Kingtron Series
|
KINGTRON SERIES
MODELS:
T336
ST336
Features:
- Size Range: 1/4″ through 2″
- 3 – PC
- Live-Loaded Packing
- Forged Body
- Weld-In-Place Design
- Blow-Out Proof Stem Design
Download the Tech Bulletin Now!
|
|
|
High Pressure – Seal Weled Ball Valve
|
|
FloTron-II SERIES
MODELS:
S6000-SS
S6000-CS
Features:
- Size Range: 1/4″ through 2″
- Seal Welded Body
- Blow-out Proof Stem Design
- NACE MR0175-90
- Heavy Duty, Rugged Construction
- Lockable Handles
- API 507-4 Fire Safe
- Anti-Static Ground
- Actuator Mounting Pad
Download the Tech Bulletin Now!
|
|
| |
|
|
|
3 Piece Valves
| 3 PC Full Port Ball Vales
|
|
MULTI-CHOICE SERIES
MODELS:
300-316SS
200-WCB
Features:
- Stainless Steel 316 SS
- Carbon Steel WCB
- Rating: 1500 WOG
- Sizes: 1/4″ through 4″
- Optional 6″ through 12″
More Features and Benefits
Download the Tech Bulletin Now!
|
|
|
| 3 PC Direct-Mount Automation Series
|
|
AUTOMATION SERIES
MODELS:
DM310 -Threaded Ends
DM320 – Socket Weld Ends
Features:
- 3-Piece Body, Full Port Design
- 1/4″ to 3″ Sizes
- Threaded or Socket-Weld Ends
- Body: CF8M, 316SS
- RTFE Seats
Download the Tech Bulletin Now!
|
|
|
|
3 PC High Performance Fire Safe Valve
|
|
TRI-PRO SERIES
MODELS:
HPF50 – 316SS
HPF40 – WCB
Features:
- Weld-in-Place Standard
- Protected Seat Design
- Two Fully Contained Body Seals
- Cap Screw Body Assembly
- 17-4 PH Stem Standard
Download the Tech Bulletin Now!
|
|
|
|
True Bore Extended Tube & Clamp Ends
|
|
FOR HIGH PURITY APPLICATIONS
MODELS:
350 – Clamp End
370 – Extended Tube End
Features:
- Size Range: 1/2″ through 6″
- True Bore Design
- High Surface Finish
- Full Body Cavity Filters Available
- Clean-in-Place Optional Purge Ports
Download the Tech Bulletin Now!
|
|
|
|
3PC Full Bore Ball Valve
|
|
TRI-STAR SERIES
MODELS:
510SS NPT – 316SS
520SS SW – 316SS
410CS NPT – WCB
420CS SW – WCB
Features:
- Size Range: 1/4″ through 2″
- Pressure rating: 1500 CWP – 150 SWP
- ISO-5211 Type Pad
- Full Port Design
Download the Tech Bulletin Now!
|
|
|
| Multi Choice Weld-In-Place
|
Multi-Choice Weld-In-Place
MODELS:
BUTT WELD 335-SS(Stainless Steel)
BUTT WELD 335-CS(Carbon Steel)
SOCKET WELD 325-SS (Stainles Steel)
SOCKET WELD 325-CS (Carbon Steel)
Features:
- Size Range: 1/4″ through 4″
- Pressure rating: 1500 WOG – 150 WSP
- Safer installation
- Reduce Labor Cost
- High Temp Body Seals Standard
Download the Tech Bulletin Now!
|
|
3PC High Pressure Ball Valve
|
|
H27 SERIES
Features:
- Size Range: 1/4″ – 2 1/2″ up to Class 2500; 3″ – 8″ up to Class 1500
- Body: Stainless Steel, Carbon Steel
- Full Port or Reduced Port Design
Download the Tech Bulletin Now!
|
Flanged Valves
| 2 PC Full Bore Flanged End Ball Valves
Ideal for Process and Petrochemical Applications.
|
|
 |
|
FULL-FLO / UNI-FLO SERIES
MODELS:
F150 – Class 150
F300 – Class 300
Features:
- Floating Ball Design
- Size Range: 1/2″ ~ 12″
- Fire Safe – API 607-4
- I-SO Type Mount Actuator Mounting Pad
- Live Loaded Stem Design
- Super-Tek Seating
Download the Tech Bulletin Now!
|
|
|
|
|
|
|
| Control Performance Series
Ideal valve for Clean or Dirty Liquids, Gases and Fibrous Suspension Applications
|
Control Performance Series
MODELS:
Stainless Steel – CP-SF150-SS
Carbon Steel – CP-SF150-SS
Features:
- Trunnion – Ball Design
- Size Range: 3″ ~ 12″
- Available Flanged or Wafer Models
- I-SO Type Mount Actuator Mounting Pad
- Live Loaded Stem Design
- Spring Loaded Seating
Download the Tech Bulletin Now!
|
| Trunnion Series Ball Valve
Consult Factory for Complete Valve
Model Number
|
|
|
|
|
| Wafer/Flanged Full Bore Ball Valve
A Compact Valve designed for Applications where Space and Weight are of Critical Concern
|
|
KOMPACT SERIES
MODELS:
W150SS
W150CS
Features:
Download the Tech Bulletin Now!
|
|
|
| Full Port Flanged End – Floating Ball
Economical Contractor Design
|
|
EC – SERIES
MODELS:
KF 150 – Class 150
KF 300 – Class 300
Features:
Download the Tech Bulletin Now!
|
Multi-Port Valves
|
|
| 3 & 4 Way Multi-Port Ball Valve
Simplify All Aspects of Piping Systems with Flo-Tite’s Multi-Port Ball Valves
|
|
|
|
MULTI-PORT SERIES
MODELS:
Flanged Ends:
MPF15 – ANSI Class 150
MPF 30 – ANSI Class 300
Threaded Ends:
MPT 15 – ANSI Class 150
MPT 30 – ANSI Class 300
Features:
- Trunnion Support Type, One Piece Ball/Stem
- Three Seat Design
- Actuator Mounting Pad
- Anti-Static Grounding Device
Download the Tech Bulletin Now!
|
|
|
|
|
|
| MULTI PORT 3PC 3-WAY BALL VALVES
Provides greater design flexibility making the Flo-Tite valve a valuable choice for a variety of applications
|
|
|
|
BOTTOM FLOW SERIES
MODELS:
Threaded Ends:
MPT 83 – 200 WOG
MPT 82 – 200 WOG
Socket Weld Ends:
MPS 83 – 200 WOG
MPS 82 – 200 WOG
Features:
- Size Range: 1/2″ ~ 2″
- Stainless Steel or Carbon Steels
- Optional Flanged Ends Available
- Optional “T” Ports Available
Download the Tech Bulletin Now!
|
|
|
|
|
|
| 3 & 4 Way Multi-Port Ball Valve
Quality Investment Casting with All Stainless Steel Construction
|
|
|
|
MULTI-PORT SERIES
MODELS:
MPT 100
Features:
- Size Range: 1/4″ ~ 2″
- Locking Handle at 90° Intervals
- Investment Casting
- 800 WOG Rating
- Stainless Steel Construction
- I-SO Type Mount Actuator Mounting
Download the Tech Bulletin Now!
|
|
|
|
|
|
| 3 – Way Brass – Multi-Port Series
Quality Investment Casting with All Stainless Steel Construction
|
|
|
|
3 WAY BRASS, MULTI-PORT SERIES
MODELS:
MPT 355 – T-Port
MPT 365 – L-Port
Features:
- T-Port & Diverter Type Ball Valves
- Threaded Ends
- Standard Port
- Size Range: 1/4″ ~ 3″
- Four Seat Design
Download the Tech Bulletin Now!
|
|
|
|
|
|
| Multi-Port 3-Way Flanged Ball Valves
Flo-Tite’s Bottom Entry Series Provides Greater Design Flexibility making it a Valuable Choice for Multiple Applications
|
|
|
|
|
BOTTOM ENTRY SERIES
MODEL:
MPF 155
Features:
- ANSI Class 150
- Size Range: 2″ ~ 6″
- Available in Stainless or Carbon Steel
- Compact Size and Low Weight
- One Piece Body Design
- Replaceable Seats and Seals
- Fire Safe – API 607 4th Edition
Download the Tech Bulletin Now!
|
|
|
| Modulating Control-Ball Valve – V Type
For information regarding Flo-Tite’s Modulating Control-Ball Valve V-Type, please refer to the V-Port Control Valves Section.
|
|
|
|
| Severe Service Metal Seated Valves
Extreme Service Valves Designed For Applications Where Temperatures
Exceed 800 °F
|
|
|
| SEVERE SERVICE SERIES
MODELS:
Metal seating is available for:
- Super-Flo Series
- Flanged End Full Port (150 & 300 lb)
- UNI-Flo Series
- Flanged End Standard Port
- 3 PC Designs
- Multi-Task and Tri-Pro Series
- Threaded, Socket, or Butt Weld Connections
- Multi-Task ANSI 300, Max Temp 600 °F
- Tri-Pro ANSI 600, Max Temp 800 °F
Flo-Tite can work with you to design valves tailored to your specific needs. Our knowledge of applications, materials, and design allows our engineers to find solutions to problems quickly and effectively.
Download the Tech Bulletin Now!
|
|
|
|
|
|
|
| |
| UNIQUE ESCAPING BALL DESIGN
Unique Problem solving ball designs eliminate most common problems
found in the typical ball valve
Flo-Tite’s escaping ball design relieves ball-seat contact during the 90-degree rotation. Full ball seat contact is made at the beginning and at the end of the valves 90-degree stroke. This limited contact results in longer life with lower operating torques and improved overall performance. The escaping ball design is an exceptional design for metal seated valves when class VI shut-off is required.
To learn more: Download the Tech Bulletin Now!
|
|
| |
|
| |
Media Containment Cap
For information regarding Flo-Tite’s Media Containment Cap Valves, please refer to the Media Containment Section.
|
|
|
|
| Tank Valves
For information regarding Flo-Tite’s Tank Valves-Flush Bottom Series, please refer to the Tank Valve Section.
|
|
| |
|
| Fusible Link Valves
For information regarding Flo-Tite’s Fusible Link Valves, Please refer to the Fusible Link Valve Tech Bulletin. |
|
| Steam Jacketed Valves
For information regarding Flo-Tite’s Steam Jacketed Series, please refer to the Steam Jacket Tech Bulletin.
|
V-Port Control Valves Flo-Tite’s Quarter Turn Solution to Control Valves
Control valves are considered the most important element in the control loop. For many years, the common globe valve was the traditional control element in the process industry. However, these valves have many drawbacks along with their fine qualities as control valves. Many important features like shutoff capability, flow capacity, dynamic stability, operating forces, stem leakage, handling of dirty fluid, weight and bulkiness as well as maintenance and cost have led valve manufacturers to seek other solutions for the right valve technology. Recently, quarter turn ball valves have been applied to many control applications with great success. The simple ball valve construction along with a new controlling device has introduced to the industrial market a controlling element solution that can be utilized in many applications. The ball valve has many advantages over the globe valve due to its inherent high flow capacity, floating ball design, seat wiping action and rotary stem. These together with a new seat technology and modular building of computer linked control elements give the ball valve superiority and cost effective performance in the fast growing world of modern technology.
Features of the Modulating Control-Ball Valve – V Type
- Zero seat leakage with positive shutoff
- High flow capacity
- Wide range.
- Outstanding repeatability
- Excellent stability with minimum hysteresis
- Precise control
- Specially lapped ball and seat with precise mating
- Compact size compared to linear control valves
- Various seat designs for different flow characteristics
- Various coating with low-friction and anti-abrasion features
- Rotary stem minimizes fugitive emissions
- Easy maintenance and low operating cost
- Modulated construction of control elements
- Available as 3-piece valve or flanged valve according to ANSI or DIN standard
| |
| Modulating Control-Ball Valve – V Type
30° Port 60° Port
|
|
| |
|
MODELS:
- Flanged Ends 150 and 300 lb
- 3PC Threaded, SW and BW
NOTES:
- Modulating V-Ball provides accurate control of the down stream flow rates, from simple on-off to modulating control applications. The throttling part of the ball valve is a solid stainless steel ball, not an insert like others.
- A unique design that is forgiving and accommodating.
- Flo-Tite’s V-Ball design is characterized to meet all custom flow requirements.
FEATURES:
- Higher Flow Capacities
- Excellent Repeatability
- Bubble-Tight Shut-Off
- Controllable Flow Rates
- Non-Clogging Flow-Streams For General And Slurry Applications
- Compact Control Package
- Economical Low Operating Cost
- Self-Compensating Live-
Loaded Stem Packing
- High Temperature Seats
- Pneumatically Or Electrically
Controlled, 3-15 PSI or 4-20 MA
Download the Tech Bulletin Now!
|
|
|
Tank Valves
| |
3 PC Full Bore Tank Valve
Flush bottom valves meet ASME boiler and pressure vessel code section 8, tank flange class 150 and 300.
|
|
|
FLUSH BOTTOM SERIES
SERIES:
TK300
Features:
- Size Range: 1″ through 8″
- The geometric design of the valve pad is an integral part of the surface, allowing a smooth flow preventing stagnation of the media, resulting in a perfect adaptor between the tank and the valve body.
- Our Flush Bottom Series minimizes the dead space between the valve ball and the tank.
Download the Tech Bulletin Now!
|
|
|
